RX Industries

Frp Recessed Cover

2,365.0021,615.00

SKU: N/A Category:

“Default product color is Grey. For other color options, please call us before placing your order.”

RX Industries’ FRP recessed covers are lightweight, corrosion-resistant, and durable, ideal for urban and industrial flooring. RX Industries offers customizable sizes, meeting BS EN 124 standards. RX Industries ensures high load capacity, slip resistance, and low maintenance, maintaining seamless floor finish continuity.

ItemLoad Capacity (M.Ton)Clear Opening (A)Cover Size (B)Frame Size (c)Frame Height (D)Cover Thickness (H)Recessed Height (h)Weight (Kg.)
Square2.5/5/10/20300x300375480907040/10023
2.5/5/10/20450x450530630907040/10034
2.5/5/10/20600x600670770907040/10053
10/20/1940750x7508309301108040/10095





Frp Technical Diagram

Physical Characteristics Of Frp Recessed Cover

CharacteristicDetails
Shape AvailableCircle, Square, Rectangle, and Customized
Working Temperature-10 to 120 degrees Celsius
NoiseReduced noise and vibration
ConductionNon-electricity and heat conduction
ColorStandard gray (customization available)
Surface TreatmentAnti-slip, anti-UV
TechniqueMold Pressing
PackingCardboard or as per customer's need

Technical Specification Of Frp Recessed Cover

DescriptionR.X. Manhole Cover Performance
Longitudinal Strength250 - 600 MPa
Compressive Strength300 - 600 MPa
Stretch Modulus25 - 35 GPa
Break Elongation Ratio1.3 - 10.0%
Bending Strength700 - 1400 MPa
Poisson's Ratio0.35
Relative Density1.11 - 1.15
Water Absorption (24h)10 - 30 mg

Frp Manhole cover

Load Testing Of Frp Recessed Cover

FRP/GRP/COMPOSITE products are tested for LD (2.5/5 Mt), MD (10 Mt), HD (20 Mt), and EHD (35 Mt and above) load-bearing and permanent set as per BS EN: 124IS: 1726 (1991). BS EN: 124 is a testing code worldwide for manhole covers in cast iron, ductile iron, and other materials.

Permanent Set is a multiple loading test to determine the permanent deformation in covers after multiple loading within a short time as specified in the code.

We have an in-house testing facility where we conduct regular tests batch-to-batch for quality consistency in the product.

Size

225×225, 300×300, 450×450, 600×600, 750×750

Load Capacity

2.5 Ton, 5 Ton, 10 Ton, 20 Ton, 40 Ton
